Expand your digital manufacturing catalog with this complete 5-Piece Hot Dish Trivet Vector & 3D Model Pack, pre-scaled to a standard 200mm diameter. Specially engineered for both subtractive and additive digital fabrication, this release includes precision 2D cut vectors, 3D parametric solids, and print-ready mesh files, along with an included PDF Manufacturing Settings Guide.

Each design combines intricate geometric patterns with optimized heat-dissipation geometry to protect kitchen countertops and dining tables from hot pots and dishes.

Product Features & Technical Details:

5 Distinct Geometric Patterns: Engineered for high airflow, structural stability, and sleek tabletop aesthetics.

Standard 200mm Diameter: Scaled to 200mm (7.87 in) outer diameter—easily rescalable in your CAD/CAM or slicer software.

2D & 3D Fabrication Ready: Includes clean vector geometry for laser/CNC cutting alongside watertight 3D solid and mesh models for 3D printing and 3D CAM carving.

Complete PDF Manufacturing Guide Included: Contains detailed speed/power tables for laser cutting, feeds and speeds for CNC routers, and slicer settings for 3D printing in heat-resistant filaments (PETG/ABS).

Multi-Material Compatibility: Optimized for hardwoods (Oak, Walnut, Beech, Mahogany), plywood, MDF, acrylic, aluminum, brass, and 3D printing filaments.Included File Formats:

DXF: 2D CAD vector format optimized for CNC routers, laser cutters, and plasma/waterjet tools.

SVG: Clean vector format for CO2, diode, and fiber laser cutting software (LightBurn, LaserGRBL, etc.).

STP (STEP): Parametric 3D CAD model file for engineering modification and advanced 3D CAM toolpaths.

STL: High-resolution mesh model file ready for FDM/SLA 3D printing slicers (Bambu Studio, PrusaSlicer, Cura).

OBJ: 3D object geometry file compatible with standard 3D rendering and design software.

PDF: Comprehensive Manufacturing & CNC/Laser Settings Specification Sheet.

Manufacturing settings

PDF FOR manufacturing guide INCLUDED
