Industrial Aluminum Die Casting Machine — K380 Style

Detailed 3D model of a cold-chamber high-pressure die casting machine. Suitable for foundry visualization, factory layout planning, equipment placement in BIM projects and technical presentations.The model features a machine base, clamping mechanism, tie bars, injection unit, hydraulic accumulators, protective enclosures, inspection windows, access panels and an operator control station.

Model Specifications

Parameter/ Value

Overall dimensions, length × width × height/ 6.862 × 2.456 × 3.153 m

Mesh objects/ 66

Triangular faces/ 61,448

Vertices in Blender/ 105,460

Materials/ 20

Texture resolution/ 512 × 512 pixels

Texture maps/ Base Color, Roughness, Metallic, OpenGL Normal

UV mapping/ Included

Animation and rigging/ Not included

Materials represent light and charcoal-painted panels, metallic surfaces, blue mechanical components and tinted glass.

Included Formats

Blender, FBX, OBJ with MTL, GLB, USD, STEP, STL, IFC, BIMx and GSM for Archicad 25.Mesh formats include textures. GLB contains embedded textures. CAD and BIM formats are supplied without PBR maps. IFC includes equipment properties, while GSM provides a single placeable library object with a simplified floor-plan representation.The model is intended for visualization and equipment layout planning. It is a stylized interpretation of the K380, not an exact manufacturer’s CAD model. The geometry is not prepared for fabrication, 3D printing or direct use as an optimized game asset.
