Weld-neck flanges 2 inches ASME-ANSI 3D print model

Description

This pack contains the next weld-neck flanges 2" ruled by ASME/ANSI B16.5:

-Weld-neck flange 2" RF STD #150

-Weld-neck flange 2" RF STD #300

-Weld-neck flange 2" RF STD #400

-Weld-neck flange 2" RF STD #600

Write comment
Item rating
1 0
S
stringer1963
stringer1963 2023-03-01 22:12:54 UTC
Recommended
Flange is great, just what I needed. Prints great. I will be downloading more sizes as I need them. Thanks a bunch. If you could I'd like to see a 24" vessel manway with davit arm and manway cover.
Weld-neck flanges 2 inches ASME-ANSI
$3.99

Royalty Free License
Weld-neck flanges 2 inches ASME-ANSI
$3.99

Royalty Free License
EEngineeringAccessories
EngineeringAccessories
(1 reviews)
Response 71% in 7.6h
3D Modeling
3D Print Modeling
Hire me

3D Model formats

Format limitations
  • Autodesk Inventor 2021 (.iam, .ipt)1.92 MBVersion: 2021Renderer: Octane
  • OBJ 2021 (.obj, .mtl)1.92 MB
  • Stereolithography 2021 (.stl)1.92 MB

3D Model details

  • Publish date2022-12-10
  • Model ID#4159891
  • Ready for 3D Printing
