Recommended FDM Printing Settings

To achieve maximum dimensional accuracy and durability, we recommend the following FDM printing settings:

For models 5 inches and larger, use 10 bottom layers, 10 top layers, and 8–12 wall lines.For models larger than 6 inches, increase the wall count to 12–15 wall lines for maximum rigidity and strength.Layer height: 0.08 -0.12 mm. This provides the highest surface quality and excellent detail reproduction.Always dry the filament before printing and properly tune retraction settings to minimize stringing.PLA is not recommended, as it has poor heat resistance and may deform under elevated temperatures.PETG is the recommended material for most applications. Higher-performance engineering filaments can also be used if required.The higher the quality of the filament, the better the dimensional accuracy, surface finish, and overall print quality. For best results, we recommend using premium filaments from reputable manufacturers.All molds feature a standard 16 mm injector port diameter, which is compatible with approximately 99% of silicone bait injectors currently in use.

Also, don't forget that you can improve the quality of your model and give it a glossy finish by coating it with UV resin or UV clear coat. One coat works well, but two coats will give the best results.
