Wall Mounted Spray Can Rack CAD Model – MS APEX DESIGN

This Wall Mounted Spray Can Rack CAD Model by MS APEX DESIGN is a professional workshop storage solution designed for garages, maintenance departments, fabrication shops, industrial facilities, and DIY workspaces.

Designed as a wall mounted rack, spray can holder, garage organizer, and workshop storage system, this fabrication-ready CAD model helps keep frequently used aerosol products organized, visible, and easily accessible.

This fully editable CAD package includes professional engineering files suitable for customization, manufacturing, educational projects, and workshop organization applications.

INCLUDED FILES

STEP Files (.STEP / .STP)DXF Files (.DXF)SolidWorks Part Files (.SLDPRT)SolidWorks Assembly Files (.SLDASM)Technical DrawingsProduct Render Images

FABRICATION READY DESIGN

This model has been developed for real workshop environments and is suitable for:

CNC Laser CuttingSheet Metal FabricationPress Brake BendingWelding and AssemblyWorkshop ProductionPrototype DevelopmentIndustrial Manufacturing

The design structure is optimized to simplify fabrication workflows and reduce production time.

WORKSHOP STORAGE SOLUTION

This spray can rack provides an efficient storage system for:

Spray Paint CansAerosol ProductsLubricantsPenetrating OilsSilicone SpraysBrake CleanersMaintenance SuppliesWorkshop Chemicals

The angled shelf design improves visibility while allowing quick access to frequently used products.

PERFECT FOR

Workshop OwnersMechanicsMaintenance TechniciansFabrication ShopsDIY BuildersMechanical EngineersCAD DesignersEngineering Students

The included files provide an excellent reference for sheet metal design, workshop organization systems, garage storage solutions, and fabrication-ready CAD projects.

FULLY CUSTOMIZABLE

The model can easily be modified according to project requirements:

Overall DimensionsHole DiameterHole QuantityShelf ConfigurationMaterial ThicknessMounting DetailsSurface Finishes

Whether you need a spray can holder, garage storage rack, workshop organizer, aerosol storage system, or custom sheet metal project, the design can be adapted quickly.

PRODUCT SPECIFICATIONS

Overall Width: 566 mmOverall Height: 706 mmHole Diameter: Ø72 mmHole Spacing: 122 mmMaterial: Steel (S235)Assembly Method: M4 Pop Rivets

DIGITAL PRODUCT

This listing is for a digital download only.

No physical product will be shipped.

Files are provided for engineering, educational, visualization, customization, and manufacturing purposes.

MS APEX DESIGN specializes in fabrication-ready CAD models focused on workshop storage, garage organization, sheet metal fabrication, industrial equipment, and professional engineering projects.
