INDUSTRIAL STORAGE RACK CAD MODEL

Designed by MS APEX DESIGN, this Industrial Storage Rack CAD Model is a professional fabrication-ready storage solution developed for workshops, warehouses, garages, maintenance facilities, production areas, and industrial environments.

This adjustable steel shelving system features a robust bolt and nut assembly structure, providing strength, durability, and easy installation. The rack is designed using 1.5 mm stainless steel components and can be manufactured using standard sheet metal fabrication processes.

The adjustable shelf design allows users to modify shelf positions according to storage requirements, making it suitable for tools, spare parts, equipment, storage bins, workshop supplies, and industrial inventory.

FABRICATION READY DESIGN

This model is prepared for real-world manufacturing and includes production-ready engineering files suitable for:

• Laser Cutting• Sheet Metal Fabrication• CNC Manufacturing• Workshop Production• Industrial Storage Applications

KEY FEATURES

• Adjustable Shelf Height System• Heavy Duty Steel Storage Rack• Bolt & Nut Connection Design• 1.5 mm Stainless Steel Construction• Modular Industrial Shelving Structure• Fabrication Ready CAD Model• Workshop and Warehouse Storage Solution• Easy Assembly Design• Fully Customizable Dimensions• Professional Engineering Layout

DIMENSIONS

• Height: 2000 mm• Width: 1200 mm• Depth: 430 mm

FILES INCLUDED

• STEP Files (.STEP / .STP)• DXF Files (.DXF)• SolidWorks Part Files (.SLDPRT)• SolidWorks Assembly Files (.SLDASM)• Technical Drawings• High Quality Render Images

APPLICATIONS

• Industrial Storage Systems• Warehouse Shelving• Workshop Organization• Garage Storage Solutions• Manufacturing Facilities• Maintenance Departments• Tool Storage Applications• Inventory Management Systems

FULLY CUSTOMIZABLE

The design can be modified according to your project requirements:

• Shelf Quantity• Shelf Spacing• Overall Dimensions• Material Thickness• Connection Details• Structural Configuration

SOFTWARE COMPATIBILITY

Compatible with:

• SolidWorks• AutoCAD• Fusion 360• Inventor• Blender• Most CAD software supporting STEP and DXF formats

IMPORTANT

This is a DIGITAL DOWNLOAD product.

No physical item will be shipped.

MS APEX DESIGN specializes in professional industrial CAD models, workshop equipment, fabrication projects, storage systems, manufacturing solutions, and engineering-ready designs.
