4x3 Blank Die Set Engineering Package 3D model
DESCRIPTION

This package contains a complete blank die set design ready for manufacturing and customization.

Included in the package:

Complete 3D STEP AssemblyIndividual STEP Files for All ComponentsManufacturing Drawings (PDF)Detailed Plate DocumentationAssembly Reference Model

The die set is designed as a professional tooling foundation that can be adapted for custom blanking, piercing, forming, and stamping die projects.

Suitable for:

Tool & Die DesignersManufacturing EngineersTooling WorkshopsTechnical Training and EducationCustom Die Development

All components are provided with detailed documentation to simplify manufacturing, assembly, and future modifications.

Related Tagsdiesetblankstampingtooltoolingdesignengineeringmanufacturingdrawingstepfilemechanicalcadtechnical
