Lotus Lamp Free 3D print model

third prize winner of the POLYMAKERCHALLENGE

This Ambient Lamp is inspired by the Lotus Flower. It consist out of 10 parts mainly to make it FDM printing ready. Print support is still necessary for the “center.stl”, “mid.stl” & the “bottom.stl” parts. The mid & bottom parts are printed in translucent Green PET-G and the center was printed in White PLA. The PLA is translucent enough :-) with the settings : 0.2mm layer hight, 0.8mm top/bottom thickness, 0.8mm wall thickness & 20% infill. Inside this example are 1 Red, 1 Green and 1 Blue LED. The bending of the light in the center part makes a Rainbow at the top of the Lamp. I tried to photograph it and succeeded a little bit. You can see it on one of the Pictures :-) Also the overall color of the lamp can change by dimming the LEDs individually. The dimensions of this Lamp Assembled are 142,16mm x 146,257mm and 72.18mm high.

Of course other Light sources can be used as long as it fits :-) The hole for the Light source (in the center part) has a radius of around 32mm (inside is egg shaped)

Also included is a exploded view of the Lamp. This makes it easier to see how it all comes together.

If you have questions, feel free to ask :-)
