Six-piece Puzzle 001

Six-piece Puzzle 001 Free 3D model

Description

I think this item would be good for 3D printing because it is simple to print and easy to modify the size or customize. It is also fun to play with.

This is a simple puzzle I have seen that I decided to model. It is made up of 6 identical pieces. This is a one part file to print six times, each one can be a different color. The SW2012 file is parametric with only one dimension (the end edge length) and the shell thickness. This makes scaling the puzzle a breeze. The zip file also contains an assembly file with the proper mates so you can see how it goes together and how to solve it if you have having difficulties.

I am working on getting an animation but I am not too skilled at doing this. Any help on that end would be greatly appreciated.

Item rating
0 0
Six-piece Puzzle 001
Free

Editorial No Ai License
Six-piece Puzzle 001
Free

Editorial No Ai License
Response 33% in 48.0h
3D Modeling
3D Print Modeling
Rendering
Hire me

3D Model formats

Format limitations
  • SolidWorks (.sldprt, .sldasm, .slddrw) (3 files)537 KB
  • Stereolithography (.stl)26.6 KB

3D Model details

  • Publish date2014-09-16
  • Model ID#80566
  • Animated
  • Rigged
  • VR / AR / Low-poly
  • PBR
  • Geometry Polygon mesh
  • Polygons 0
  • Vertices 0
  • Textures -
  • Materials -
  • UV Mapping -
  • Unwrapped UVs Unknown
  • Plugins used -
  • Ready for 3D Printing
