NRF24L01 Power adapter

NRF24L01 Power adapter Free 3D model

Description

Model in Solidworks 2016. Rendering in Keyshot. IGES and STEP also available.

Power adapter for NRF24L01 to power using 5V and regulate a 3.3V for the NRF24L01. Model made using caliper and parts drawings.

This model is for the NRF24L01 power adapter, but also embed the NRF24L01 model from Tristan Newman (nRF24L01+ enhanced transceiver board) for a complete assembly of NRF24L01 and its power adapter.

More infos: https://arduino-info.wikispaces.com/Nrf24L01-2.4GHz-HowTo
