Industrial Pump and Tank Piping System with Tank 3D print model

Product TitleIndustrial Pump & Tank Piping System – Hollow Tank, Flanges, Valve – GLB & Blend

DescriptionThis model represents a complete industrial piping setup, designed for engineering visualization, simulation, and digital twin applications. It includes a vertical hollow tank, a pump body, a main pipeline with flanges, and realistic flow connections. The model is lightweight, accurately scaled using SI units (meters), and ready for integration into web-based 3D viewers, game engines, or CAD pipelines.

This system was generated procedurally using Blender’s Python API to ensure precise alignment, mesh cleanliness, and consistent topology.

Model DetailsTank

Hollow vertical cylinder

Outer radius: 0.6 m

Height: 2.5 m

Wall thickness: 2 cm

Sealed with a bottom cap (open-top)

Pump

Rectangular housing (scaled cube)

Dimensions: 0.6 m × 0.4 m × 0.5 m

Positioned between inlet and outlet pipes

Piping

Pipe Diameter: 6 inches (0.1524 m)

Inlet pipe (tank to pump): 2.2 m

Outlet pipe (pump to main): 2.0 m

Main horizontal pipeline: 5.0 m

Additions

Valve handle placed on the outlet pipe

Flanges at each joint connection

All parts aligned in a single X-plane for visual clarity and logical flow
