Valve Body Design 3D print model

Valve Body STL File – Steam Flow Design (Textbook Dimensions)

This is a solid 3D model of a valve body, designed with accurate proportions based on standard mechanical engineering textbook specs. It’s built with internal paths to allow steam or fluid to pass through — just like a real valve body should. Perfect for anyone working on fluid control systems, prototypes, or mechanical design studies.

Key Details:

• Model:Valve Body
• Format: STL,OBJ,STP
• Dimensions: ~34.6 × 19.8 × 20.0 cm
• Volume: ~13500 cm³
• Purpose: Concept design, CAD study, prototyping, or as a base for modification

Why You’ll Want It:

• Based on real textbook dimensions — no guesswork
• Includes steam flow paths
• Great for students, makers, and engineers needing a ready-to-go base model
