Z-Shaped Mounting Bracket 3D print model

This is a 3D CAD model of a generic Z-type mounting bracket, designed for structural support in mechanical assemblies, industrial setups, or electronic enclosures. The bracket follows a standard Z-profile, offering two offset mounting planes suitable for connecting perpendicular surfaces.

The model is designed in CATIA with clean geometry and is provided in multiple CAD formats for compatibility with various engineering workflows. Ideal for use in simulation, product development, or hardware integration.

Features:

• Z-profile mounting bracket geometry
• Designed in CATIA
• Suitable for structural support and component mounting
• Ideal for use in assemblies, enclosures, or electronic devices
• Compatible with simulation and CAD integration

Applications:

• Mechanical structure support
• Electronic component mounting
• Industrial and automation assemblies
• FEA simulation (bracket loading or stress analysis)
• Educational projects in mechanical design

File formats:

• CATIA .CATPart
• STEP (.stp)
• IGES (.igs)
• STL (optional for visualization or meshing)
