DESCRIPTION

3D Model CAD from a Dry Sump Oil System made on CATIA V5 R21.

STEP Model + .CATProduct & 23 .CATParts

Recapitulation of: Dry Sump Oil Pump.

  • Different parts: 23
  • Total parts: 159

CATIA V5 (R21 >) flies contains:

  • Kinematics Simulation.
  • 3 sequences (Disassembly, Disassembly + Cam tracking & Kinematics Simulation + Cam tracking).
Related Tagsoilsumpcarmechanismpulleylobemachineryassemblyengine
lubrication
scienceengineeringcar engine
