EL (HAND) - ANATOLIAN AMULET PENDANT

A production-ready pendant based on the El (Hand) motif from traditional Anatolian kilim weaving.The open hand is one of the oldest protective signs in Anatolia - worked into kilims, and into the amulets women wore, to turn away the evil eye.The design keeps that reading direct: five fingers across the top, the palm below them, narrowing to the wrist.

Modeled in Rhino as a clean, closed, watertight solid.Ready for resin printing and direct casting - no repair or remeshing needed.

DIMENSIONS

Width 14.10 mmHeight 16.50 mmThickness 1.65 mmBail 4.80 mm (integrated, fully modeled)Bail opening 1.25 mmMinimum wall 0.30 mm

GEM REPORT - 72 stones

Shape Size QtyRound 1.00 mm 62Round 1.30 mm 10

Total diamond weight 0.317 ctTotal CZ weight 0.501 ct

The ten 1.30 mm stones sit in the fingers, two to each finger, so the hand reads clearly at wearing size.All stones are modeled in place with cut seats and sit on a separate layer, removable in one click.

METAL WEIGHT ESTIMATE

Yellow Gold 10K 1.40 gYellow Gold 14K 1.57 gWhite Gold 10K 1.34 gWhite Gold 14K 1.54 gSterling Silver 925 1.27 gSteel 0.94 gWax (CNC) 0.12 g

WHAT YOU GET

• .3dm native Rhino file, organized layers (metal / stones / bail)

- .stl print-ready mesh, watertight, correct scale in mmNOTES

• Scale to any size you need; built at real jewelry scale in mm
• The seats accept any round stone of the listed sizes - diamond, CZ, ruby, sapphire or garnet
• Suitable for silver, gold and steel casting
• Designed by a jewelry CAD designer, not converted from a render mesh

Part of an ongoing series of pendants drawn from the traditional Anatolian kilim motif vocabulary.

Renders are for presentation only. Stones, chain and background are not included in the files.
