DUNE pairs a gently curved silhouette with 46 sculpted vertical grooves and a separate, deep saucer. Elongated rounded groove openings flow into a softly curved lower body, above a discreet foot ring.

The planter includes seven drain holes and four channels beneath the foot to let water reach the saucer. The two parts are supplied separately for printing, with flat bed placement in each STL and 3MF file.

DIMENSIONS

• Body height: 150 mm; planter height including foot: 153.3 mm.
• Maximum planter diameter: approximately 155 mm.
• Saucer: nominal 138 mm diameter x 21 mm height (rounded outer edge).
• Total assembled height: 156.3 mm.
• Planter floor: 4.5 mm. Saucer floor: 3 mm.
• Nominal wall before grooves: 6 mm. Groove depth: 3 mm.
• Drainage: one 9 mm center hole and six 6 mm holes; four foot outlets.

INCLUDED

• Two separate STL and 3MF print files.
• STEP assembly and FreeCAD solid model.
• Blender product and studio scenes.
• OBJ with MTL, FBX and GLB exchange files.
• English and Turkish product/printing guides.

PRINTING

Print both parts upright. The planter needs build-plate supports under the recessed bottom and lower overhang; the saucer was digitally sliced without supports. Block supports above Z = 20 mm to keep tall automatic pillars away from the upper flutes; an optional PrusaSlicer support-blocker setup is included. Clear the drainage openings after removing supports. Do not use vase mode. Use your own printer and filament settings; the guide includes a digital review starting point.

Digitally checked, not physically test-printed. Printed fit, support removal, water flow and tray watertightness still require a real print test. Test for leaks before use on furniture and empty standing water.

Studio and technical images are rendered from the supplied model. Lifestyle scenes are AI-generated illustrations and may differ in proportions, details and colors. Plants, soil and decorative props are not included. Images are not photographs of a physical print. Final printed appearance depends on your filament and printing process.

High-resolution CAD-derived meshes; intended for printing and product visualization, not optimized as a low-poly game asset. No UV texture set is included. Procedural studio materials are provided in the Blender scene; exchange formats contain a simple matching base material.
