Connector was created for custom adapters. It is not toy 3d model, it's full real dimension comparsion. The part is produced in a certain quantity and tested in practice, you can find confirmation on my profile. Size matching guaranteed, Tested by me in practice. For additional advice, please contact me. You can use it for manufacturing, projecting your custom thigs or just render.
!!! Attention !!! The project was created before the publication of the open standard NACS (Tesla), so some of the dimensions do not correspond to it and were assigned at my discretion. However, the design is fully functional. Initially, some elements were simplified in order to facilitate manufacturing by CNC milling. !!!
Project contains files PDF 3d\IGES(igs)\STEP(stp)\STL\3MF\AMF. The archive contains a 3D model in two versions, without internal pins and with their presence Check my other EV connectors 3d models. Any questions. Open for work.
