The highly detailed 3D printable model of 727-200 with the designation of doors, windows, air intakes, high-lift devices. Antennas and flap track fairings are made in separate parts.

• Model code: 26206 Model kit 727-200 Up [fm]
• Version: with full designation and magnetic mounting*
• Revision: original (2025-08-16)
• Scale: 1/72
• Winglets: without
• Engines: JT8D-9
• Landing gear: up
• Model length: 64.8 cm
• Wingspan: 45.7 cm
• Parts quantity : 50 (without magnets) / 104 (with magnets)
• 3D print complexity: 4/5
• Assembly complexity: 3/5
• Decals: 262D01-IBE Iberia (1977)

*allow you to assemble/disassemble the models for easy transportation and storage. However, you can assemble this model without using magnets, for this you need to glue the appropriate parts.

The model requires gluing. 3D Printing Guidelines and Assembly Instructions are included.

Importantly! The model is divided into parts that are oriented for easy printing. Solid model not included in this kit.

If you want to know more about current projects, follow me on Facebook or Instagram.

https://www.facebook.com/AirCADer.Models/

https://www.instagram.com/aircader.models/

If you want to print and sell my models, please contact me first.

3D printing settings

The model is optimized for FDM printer with 0.4 mm nozzle. Parts were tested on 3D printers Anycubic Viper and Qidi Q1 Pro. Approximate ⌀1.75 mm filament length for one model (without stand) - 163 meters. The manual includes information about supports and printing recommendations.

Files format: .stl Providing files in other formats must be discussed separately.

Dimensions of the largest parts (in mm):

• Fuselage Center: 52.2 x 59.3 x 201.1
• Wing left/right: 16.1 x 185.3 x 217.2
• Stand: 129.8 x 149.8 x 124.6
