Spur Gear 220mm OD with Keyway 3D Model 3D model
DESCRIPTION

High-precision 3D model of a Spur Gear designed in SolidWorks 2021 based on detailed engineering specifications (220mm Outer Diameter, 200mm Pitch Diameter, 20mm Thickness, and 60mm Bore). Ideal for mechanical engineering, industrial applications, assemblies, and 3D printing.

Features:

Designed precisely in SolidWorks 2021

Includes engineering drawing file (SLDDRW)

Accurate dimensions, keyway, and weight-reduction pockets

Ready for 3D printing, manufacturing simulations, and rendering

Available Formats:

SLDPRT, SLDDRW, STEP, IGES, STL, 3MF, X_T, ZIP

Gear Specifications (Based on Drawing)

Gear Type: Spur Gear

Outer Diameter (OD): 220.00 mm

Pitch Diameter: 200.00 mm

Thickness / Face Width: 20.00 mm

Bore Diameter: 60.00 mm (with 40.00 mm inner hub / keyway details shown)
