Automatic Booster Impeller Assembly and Pressing Integrated Assembly Line

Introduction

Non-standard automatic pressurized impeller assembly and pressing line body includes timing analysis diagram description

  1. This production line is composed of multiple assembly machines + various types of conveyor lines, so as to realize full-line automation Brand, so as to ensure the stability and service life of the equipment;
  2. Equipment performance: beat: about 38s/1PCS
  3. Equipment shape parameters and required number of operators:

    3.1. The length of the line body is 9 meters, the width is 4.5 meters, and the working height is 0.9 meters .

    3.2. A total of one person is required for the line body to operate the feeding, loading and unloading tray, and NG unloading:
