SOLAR ENERGY GROUND MOUNTED INSTALLATION-CATALOG-1 3D model
Description
SINGLE COLUMN SOLAR ENERGY GROUND MOUNTED INSTALLATION
It is prepared in Powerpoint environment, editable and customizable format.It is prepared as a ground assembly guide for single column solar energy construction.There are 2x13, 2x7 and 2x6 panel arrays in the assembly guide and catalog.
2x13 Vertical Solar Glass Panel Layout
- 1 Table for a Flat Ground
- 1 Table for 15 Degree Inclined Ground in East-West Direction
- Indipendent Inverter Conneciton Stand
Ground Connection Type; Steel Pile Driving
Panel Dimensions : 2279 x 1134 x 35 mm
Panel Power : 550Wp
1 solar panel steel construction produces 28,6 kWp power in 1 hour
The system consists of 7 axles and the distance between each axle is 2300 mm.
Horizantal angle of panel 25°
The closest distance of the panels to the floor 800 mm.
Prepared With BLENDER Version 4.0.1
Polygons : 680621
Vertices : 993736
Objects : 2090
SOLAR ENERGY GROUND MOUNTED INSTALLATION-CATALOG-1
Royalty Free License
SOLAR ENERGY GROUND MOUNTED INSTALLATION-CATALOG-1
Royalty Free License
3D Modeling
3D Model formats
Format limitations
Native
- Blender 4.0.1 (.blend)95 MBVersion: 4.0.1Renderer: Eevee 4.0.1
Exchange
- PDF (.pdf)5.84 MB
- Other 62.5 MB
- JPG (.jpg) (2 files)93.9 MB
- PNG (.png)81.9 MB
- EXR (.exr)81.9 MB
- OBJ (.obj, .mtl) (2 files)128 MB
- Autodesk FBX (.fbx)68.7 MB
3D Model details
- Ready for 3D Printing
- Animated
- Rigged
- VR / AR / Low-poly
- PBR
- Geometry Polygon mesh
- Polygons 680,621
- Vertices 993,736
- Textures
- Materials
- UV Mapping
- Unwrapped UVs Unknown
- Plugins used
- Publish date2025-02-24
- Model ID#5892124
