ABOUT THIS BUNDLE:-Speed up your drafting workflow with this Complete House Electrical Layout plan & CAD Block. Perfect for architects, MEP engineers, interior designers, and drafting students needing professional, ready-to-use 2D electrical symbols and residential layout templates.

WHAT’S INCLUDED?

• Editable .DWG Master File (AutoCAD compatible)
• Printable .PDF Catalog (Quick visual reference index)

KEY COVERAGE:-

• Lighting & Switches: Downlights, pendants, strip lights, 1-way/2-way & dimmer switches.
• Power Outlets: Single/double 13A sockets, floor boxes, weatherproof outlets.
• Low Voltage & Panels: TV/Data RJ45, CCTV, DB panels, single-line diagrams (SLD).
• Sample Layouts & Legends: Standard mounting height details and residential wiring samples.

FEATURES:-

• 100% Editable & Scalable
• Easy Drag-and-Drop (Ctrl+C / Ctrl+V)
• Instant Download after purchase

Note: This is a digital product. Files will be delivered in a .ZIP folder.
