Emergency Exit Door

Emergency Exit Door 3D model


This is a Revit Family model for a fully parametric Emergency Exit Door. Controlling parameters can create either a wooden or an aluminium door with or without top and bottomo windows. Wide range of parameters to create an variation of an emergency wooden or aluminium internal or external exit door with panic push bar, floor or ceiling springs, top and bottom window.

Family model is a wall based family. The door adjusts to the wall that it is inserted on to. Door frame can be flush with the wall or have offset value parameters ( setback ). Wall finish takes the door frame location and adjusts accordingly if necessary to wrap the wall finish around the wall cut up until the start of the door frame.


  • Revit Version : 2022
  • Family Type : Wall Based
  • File Extension : .rfa


  • Door Rough Width and Height
  • Door Frame Width & Wall Setback
  • Frame Stopper Width
  • Architrave exterior/interior ON/OFF option
  • Architrave Width and Thickness
  • Door Leaf Thickness
  • Door Leaf Setback in relation to the door frame
  • Top/Bottom Window ON/OFF option
  • Push Bar Height
  • Floor Spring/Ceiling Spring Option, ON/OFF option
  • Door handle with lock exterior side ON/OFF option
  • All materials can be controlled

FAMILY TYPES: W1200xH2400mm, Wood Oak, Architrave, Floor Spring, No Window W1000xH2100mm, Wood White, No Architrave, Ceiling Spring, No Window W1000xH2100mm, Wood Walnut, No Architrave, Frame Setback, Floor Spring, No Window W1100xH2300mm, Aluminium, Architrave, Top Bottom Window, Ceiling Spring W1000xH2100mm, Aluminium, No Architrave, Top Window, Floor Spring

USer can create unlimited variations for any family type to match design criteria.
