Detail2Body – Fusion 360 Add-in
Extract Surface Details as Separate Bodies
Detail2Body is a powerful Fusion 360 add-in that extracts surface details from solid bodies and converts them into separate Joiner and Cutter bodies.
Perfect for kit-bashing, 3D printing, and design reuse.
What Does It Do?
When you apply features such as fillets, chamfers, or holes to a solid body, they normally become part of that body.
Detail2Body reverses this process by extracting them as separate bodies:
• Joiners — Extracted bodies representing added material
• Cutters — Extracted bodies representing removed material
• Sub-Bodies — Copies of related bodies that are not combined with the source
Build once, use everywhere.
Demo Version
• Select Source Body
• Selection Type (Features or Faces)
• Select Details
Full Version
Everything in the Demo, plus:
• Detail Sub-Bodies
• Operation (New Body / New Component)
• Component Location (Source / Active / Root)
• Select Outputs
• Create Selection Sets
• Auto-Open Tools (Move/Copy, Scale, Move to Group)
• Custom Naming Prefixes
• Custom Colors for Joiners, Cutters, and Sub-Bodies
• Advanced selection options
• Auto-save settings and reset-to-default button
• And more
Key Features
Two Selection Modes• Feature Mode — Select entire features from the timeline (fast and automatic)
• Face Mode — Manually select individual faces for precise control
Smart Output Options• Create results as New Body or New Component
• Automatic color coding for easy identification
• Generate Selection Sets for quick re-selection
• Custom naming prefixes (Source Body, Component, File, Project, or Custom)
Workflow Integration• Auto-open tools after completion (Move/Copy, Scale, Move to Group)
• Works in both Parametric and Direct Modeling modes
• Timeline grouping for clean history
• All settings are saved automatically between sessions
Full Customization• Custom names for Joiners, Cutters, and Sub-Bodies
• Multiple color options for each body type
• Component location control (Source, Active, or Root)
• Result notifications with a detailed summary
How to Use
- Select Source Body — Choose the solid body containing details
- Choose Selection Type — Features or Faces
- Select Details — Pick the features or faces to extract
- Optional: Add Sub-Bodies — Select related hardware or parts
- Click OK — Your Joiners and Cutters are created
Perfect For
• Kit-bashing — Build modular detail libraries
• 3D Printing — Extract details for multi-material printing
• Design Reuse — Create reusable detail components
• Reverse Engineering — Analyze and separate existing designs
What’s Included
• Detail2Body Fusion 360 Add-in
• Ready to install and use
Requirements
• Autodesk Fusion 360 (Personal, Educational, or Commercial license)
• Windows or macOS
Coming from Other Software?
From CAD Software (SolidWorks, CATIA, Inventor, etc.)• Import your model as STEP, IGES, or SAT
• Use Detail2Body directly on the solid body
From 3D Software (Blender, 3ds Max, Maya, etc.)• Import your mesh as OBJ or STL
• Convert Mesh Body to Solid Body first
• Then use Detail2Body on the converted solid
Support
For questions or support, please contact me via the marketplace messaging system or by email:
sup.cgtoolforge@gmail.com
Free Demo Coming soon on the official Autodesk App Store.
Thank you for your purchase!
