A collection of 20 industrial connector models for product visualization, electronic enclosures, control panels, and industrial design presentations.

INCLUDED MODELS

1. USB Type-C Receptacle
2. USB Type-A Receptacle
3. Micro USB Type-B
4. USB Type-B Receptacle
5. HDMI Type-A
6. Mini HDMI Type-C
7. DisplayPort
8. RJ45 Ethernet Port
9. SD Card Slot
10. MicroSD Card Slot
11. Nano SIM Tray
12. 3.5 mm Audio Jack
13. 6.35 mm / 1/4-inch Audio Jack
14. RCA Connector
15. TOSLINK Optical Audio
16. DC Barrel Jack
17. IEC C8 AC Inlet — Figure-8
18. IEC C14 AC Inlet
19. BNC Connector
20. SMA Connector

MODEL DETAILS• All 20 designs included in one native Rhino file• Individual model groups and named category layers• Real-world scale in millimeters, based on common connector sizes• Editable NURBS/Brep geometry in the native file• 193 valid closed solid components• Basic color materials included; no external texture images required

FILE FORMATS• Rhinoceros (.3dm)• STEP (.step)• FBX (.fbx)• OBJ with accompanying material file (.obj + .mtl)

Rhino and STEP contain CAD geometry. FBX and OBJ contain mesh geometry. Keep the OBJ and MTL files together to retain basic material assignments. Material appearance may vary between applications.

PREVIEW IMAGESOne collection overview and five category previews are provided in PNG and JPG format. Model images were captured directly in Rhino using the Rendered display mode.

Models are displayed at individually adjusted sizes in the preview layouts for clarity; previews do not represent a shared scale.

INTENDED USEThese models are designed for visualization and concept development. Internal contacts, mounting details, and threads are simplified. They are not manufacturer-certified parts and should not be used as production drawings, PCB footprints, or electrical specifications.
