The Malabar 15 Gallon Hydraulic Dispenser was modeled using the Part and Assembly environment in Solidedge

PDF reference: http://www.malabar.com/pdf/product/fluid/sd475.pdf

SPECIFICATIONS Fluid Type: MIL-H-5606 or Equal Fluid Capacity: 15 Gallon (56.8 liters) Hand Pump Displacement per Stroke: 4.0 cu. in. (66 cc) Maximum Air Operated Pump Flow: 4.5 gpm (17.0 liters) Maximum Pump Outlet Pressure: 100 psig (7 kg/sq cm) Standard Hose Length: 120 inches (3048 mm) Standard Filter Rating: 2-3 micron nominal Net Weight: 105 lbs (47.6 kg)

Easy-Roll Corrosion Resistant 304 Stainless Steel Caster Rigid, 8" x 2" Solid Urethane Wheel, 1200 lb Capacity

reference:http://www.mcmaster.com/#23355t64/=12v9kmf

Modeled in Solidedge ST6 Rendered in Keyshot 5.0
