This is a 3D CAD model of a generic stop valve body, commonly used in fluid control systems for stopping or isolating flow in pipelines or process installations. The model includes the main housing geometry without internal moving components, designed for conceptual layout, mechanical assemblies, or simulation environments.

Created in CATIA, the geometry is clean and simplified, making it ideal for integration into piping systems, plant layouts, or FEA/CFD preparation. This model can be used in both educational and professional engineering projects.

Features:

• Generic stop valve body geometry
• Designed in CATIA
• Clean structure suitable for simulation and CAD integration
• Ideal for fluid system layout, mechanical design, or conceptual development
• No internal moving parts or sealing detail

Applications:

• Fluid system design (hydraulic, pneumatic, water, gas)
• CAD layout of pipelines and control valves
• Mechanical assembly design
• Structural or thermal simulation
• Engineering training and documentation

File formats:

• CATIA .CATPart
• STEP (.stp)
• IGES (.igs)
• STL (optional for preview or meshing)
