High-Quality 3D Printable & Editable Jewelry Model – Luxury Ribbon Wrapped Jesus Crucifix Pendant

This exceptionally elegant and highly detailed cross pendant features a beautifully intertwined, pave-set ribbon/sash wrapped around the main body, complemented by a finely sculpted Corpus (Jesus figure) and a highly detailed geometric backplate. It is a premium, production-ready CAD model designed specifically for high-end fine jewelry manufacturing.

The package includes both the original, editable CAD file (.3DM) and pre-split, high-resolution mesh files (.STL) for immediate 3D printing.

Designed with the professional master jeweler in mind, this model is fully modular. The main cross, the wrapped ribbon, the Jesus figure, the patterned backplate, and the bail are all completely separate components. This allows for flawless multi-color metal casting (e.g., a Rose Gold Jesus and Ribbon on a White Gold cross with a Yellow Gold backplate), incredibly clean finishing, and easy polishing behind the micro-pave set areas before the final assembly.

Model Highlights & Features:

Design Style: Ornate Luxury, Ribbon/Wrapped Crucifix Pendant, Pavé Diamond Religious Fine Jewelry.

Fully Editable CAD: Includes the native .3dm file, allowing you to easily adjust dimensions, prong heights, or metal thicknesses to fit your workshop standards.

Modular Engineering: Intelligently split into multiple separate parts (Corpus, Ribbon, Backplate, Main Cross, Bail) to simplify casting and guarantee professional, clean stone setting.

Production Ready: Clean topology, watertight solid meshes, and meticulously checked for 3D printing and direct casting with zero errors.

Stone Specifications (Round Cut):

1.25 mm: 248 pieces

1.05 mm: 135 pieces

Total Stone Count: 383 stones

Estimated Total Carat Weight: ~2.41 ctw

Dimensions:

Width: 39.40 mm

Height (without bail): 53.84 mm

Depth/Thickness: 7.00 mm (11.83 mm at the highest ribbon curve)

Included File Formats:

.3DM: Editable Rhino / Matrix CAD file (NURBS / Curves included).

.STL: High-resolution, print-ready solid mesh files for each separate component.

Important Notes for Jewelers:

Prongs and stone seats are precisely calibrated to guarantee a smooth and secure stone-setting process after casting.

Please review the attached chart images in the gallery for estimated metal weights across various karats (Gold/Silver/Platinum).

Note: This is a digital 3D CAD file for jewelry production, not a physical item.
