Car Coinbox and Foldable Cup Holder

Car Coinbox and Foldable Cup Holder 3D print model

Description

Notes for before print;

  • Cup holder can be changed by https://aliexpress.com/item/1005002006729754.html
  • I dont use bot1.stl, and bot2.stl files because it takes 14hrs for printing. These files requires for box footer. I made it from wood and use paint with black color because it stays under the seat. I added these files if you dont want to use wood or other options etc..
  • You can use glue for body to footer part, coin box no needs.
  • I used simple fridge magnets for coin box cap, its cheap and can be found anywhere, can be cut with scissors.
  • Coin box has self hinge and needs support.
  • Cup holder screw holes 3mm you can use M3 or hardened metal wire (I dont want to use self hinge because of the fragility. Im used 3mm copper wire)
  • I recommended ABS or PETG filament. In hot climates, there is a risk of the PLA being warped inside the vehicle.
  • As an alternative to the coinbox, 4 ports USB can be used. The file is attached. https://aliexpress.com/item/32788040895.html (Also can be used non-circuit female usb port to manually connections)

  • I'm used 10% infill for body and 15% for coin box + 20% cup holder (4 Wall thickness)
