13 Lindab Integra Diffusers 3D model
thumbnail
thumbnail
DESCRIPTION

Compatible with Smart Diffusers extension.

Example of parameters from one family:

Type PC6-160-R PC6-125-R PC6-250-R Air Flow 0.00 L/s 0.00 L/s 0.00 L/s Arrow 300.0 300.0 300.0 Arrow Distance 0.0 0.0 0.0 Arrow Length 50.0 50.0 50.0 Arrow Visible True True True Ceiling Grid Opening Diameter 470.0 370.0 550.0 Ceiling Grid Opening Radius 235.0 185.0 275.0 Default Elevation 1200.0 1200.0 1200.0 Description PC6 is a circular perforated diffuser that can be used for both supply air and exhaust. The diffuser is suitable for the horizontal supply of cooled air. PC6 is a circular perforated diffuser that can be used for both supply air and exhaust. The diffuser is suitable for the horizontal supply of cooled air. PC6 is a circular perforated diffuser that can be used for both supply air and exhaust. The diffuser is suitable for the horizontal supply of cooled air. Diffuser Depth 160.0 160.0 160.0 Diffuser Diameter 460.0 360.0 540.0 Diffuser Diameter 2 400.0 300.0 480.0 Diffuser Radius 230.0 180.0 270.0 Diffuser Radius 2 200.0 150.0 240.0 Duct Diameter 160.0 mm 125.0 mm 250.0 mm Duct Radius 80.0 62.5 125.0 Face Plate Radius 241.0 191.0 281.0 Free Area 0.020 0.012 0.049 Manufacturer Lindab Lindab Lindab Max Flow 172.64 L/s 101.12 L/s 300.05 L/s Min Flow 93.13 L/s 50.81 L/s 158.55 L/s Model PC6-160 PC6-125 PC6-250 Pressure Drop 0.00 Pa 0.00 Pa 0.00 Pa T4R_Created by www.Tools4Revit.com www.Tools4Revit.com www.Tools4Revit.com T4R_Version 2011.12.27 2011.12.27 2011.12.27 Type Comments Ceiling perforated diffuser Ceiling perforated diffuser Ceiling perforated diffuser URL www.lindab.com www.lindab.com www.lindab.com Velocity 0.00 m/s 0.00 m/s 0.00 m/s Type PC6-315-R PC6-200-R Air Flow 0.00 L/s 0.00 L/s Arrow 300.0 300.0 Arrow Distance 0.0 0.0 Arrow Length 50.0 50.0 Arrow Visible True True Ceiling Grid Opening Diameter 550.0 470.0 Ceiling Grid Opening Radius 275.0 235.0 Default Elevation 2500.0 1200.0 Description PC6 is a circular perforated diffuser that can be used for both supply air and exhaust. The diffuser is suitable for the horizontal supply of cooled air. PC6 is a circular perforated diffuser that can be used for both supply air and exhaust. The diffuser is suitable for the horizontal supply of cooled air. Diffuser Depth 160.0 160.0 Diffuser Diameter 540.0 460.0 Diffuser Diameter 2 480.0 400.0 Diffuser Radius 270.0 230.0 Diffuser Radius 2 240.0 200.0 Duct Diameter 315.0 mm 200.0 mm Duct Radius 157.5 100.0 Face Plate Radius 281.0 241.0 Free Area 0.078 0.031 Manufacturer Lindab Lindab Max Flow 448.15 L/s 260.16 L/s Min Flow 232.78 L/s 117.25 L/s Model PC6-315 PC6-200 Pressure Drop 0.00 Pa 0.00 Pa T4R_Created by www.Tools4Revit.com www.Tools4Revit.com T4R_Version 2011.12.27 2011.12.27 Type Comments Ceiling perforated diffuser Ceiling perforated diffuser URL www.lindab.com www.lindab.com Velocity 0.00 m/s 0.00 m/s
Related Tagsairterminals
diffusers
lindab
industrialpartvehicleindustrial vehicleindustrial partvehicle part
