CADraw — Real-Time CAD Drafting Tools for Blender

CADraw brings reliable, precision 2D/3D CAD-style drafting directly into Blender's viewport. Built for anyone who needs accurate technical drawing without leaving Blender — architects, product designers, hard-surface modelers, and anyone laying out floor plans, blueprints, or precise base geometry.

2D Drawing ToolsPoint, Line, Rectangle, Circle, Ellipse, and Arc — draw clean 2D geometry with live numeric feedback as you work.

3D / Poly Drawing ToolsRectangle Poly, Plane Poly, Line Poly, Circle Poly, and Regular Poly generate filled, ready-to-use polygon geometry directly in 3D space.

Precision SnappingGrid, Endpoint, Midpoint, Intersection, and Center snapping keep every point exactly where it needs to be. Ortho and Polar tracking lock your lines to clean angles, and Auto-Close automatically completes Plane Poly and Line Poly chains.

Live FeedbackDashed construction guides, numeric entry, and a live length/angle readout give you full control while drawing — just like a dedicated CAD application.

Reliable NormalsFilled polygons are generated with deterministic winding using a robust area-normal calculation. In View mode, the drafting normal automatically faces the active camera, so every face you create is visible even with backface culling enabled.

Fast Keyboard WorkflowD Point · L Line · R Rectangle · H Rectangle Poly · C Circle · E Ellipse · A ArcG Grid · O Ortho · J Polar · Z Auto-Close · V Endpoint · M Midpoint · I Intersection · K CenterEnter Finish · Esc Cancel

Access everything from the View3D Sidebar under the CADraw tab.

Compatible with Blender 5.3+

Update V2:

-New Wall System-New Tools-New UI -Some Fixes
