DESCRIPTION

Hydraulic Cylinder - WeldedFile contains all parts and assemblies, with all drawings and tolerances.

Max pressure: 250 BarPiston dimeter = 100mmPiston stroke = 500mm

The product is totally my design and it is not copied from other engineers.

If you want different dimensions of cylinder or if you want different ways of mounting a cylinder, you can contact me. And I will design different cylinder for you.

Designed in PTC Creo Parametric 2.0
