Six axis fine-tuning mechanism

Six axis fine-tuning mechanism 3D model


Six axis fine-tuning mechanism, the combination of the mechanism by lead screw and guide rail, to form a space of six axis fine-tuning, similar to the six axis of the manipulator, form a spherical space adjust, very clever to realize any position adjustment, institutions are very clever, low-cost Mechanism contains:

  1. the xy adjustment platform
  2. Z axis fine-tuning mechanism
  3. Six axis Angle trimming mechanism ************************************** Files format contains -solidworks 2017 -step -iges -stl -obj -3ds -Fbx -3dmax
  4. and other formats ************************************** If you like,you can buy for you to get this models or if you have any questions also you can email to me. Designed with SolidWorks 2017, render with PhotoView 360 **************************************
