Three open electrical cabinets with internal mounting plates, DIN rails, circuit breakers, contactors, terminal strips, slotted wiring ducts, routed wires, copper earth bars, glands, door gaskets and manual door pivots. Includes a separate library of 24 component objects covering breakers, contactors, terminals, rail lengths, ducts, glands, power supply and PLC, including repeated finish variants.

CONTENTS

• 01 Wall Cabinet 600x800
• 02 Control Cabinet 800x1200
• 03 Floor Cabinet 800x1800
• 04 Component 01
• 05 Component 02
• 06 Component 03
• 07 Component 04
• 08 Component 05
• 09 Component 06
• 10 Component 07
• 11 Component 08
• 12 Component 09
• 13 Component 10
• 14 Component 11
• 15 Component 12
• 16 Component 13
• 17 Component 14
• 18 Component 15
• 19 Component 16
• 20 Component 17
• 21 Component 18
• 22 Component 19
• 23 Component 20
• 24 Component 21
• 25 Component 22
• 26 Component 23
• 27 Component 24

SOFTWARE AND FORMATSBlender 4.5.13 LTS / Cycles.FBX, OBJ + MTL and GLB are included. Units: metres. 577,880 evaluated triangles across the full library; 323,928 evaluated vertices.

MATERIALS AND PRESENTATIONOriginal 2048 x 2048 roughness and OpenGL normal maps, with additional base-color maps where applicable. Surface UVs deliberately tile and overlap; they are not a unique atlas. The supplied gallery is rendered in Cycles and composited over plain white. Any image named Corona13 is rendered in Corona 13. The component sheet frames each item independently and is not a common-scale drawing.

NOTESThree cabinet sizes: 600 x 800, 800 x 1200 and 800 x 1800 mm, excluding plinth and projecting fittings. Static visualization layouts; wiring is illustrative and not a functional electrical schematic. No animation or electrical simulation is included.Native files include editable objects and studio lighting. No third-party models or texture libraries are redistributed. No animation clips or optimized game LODs are included. OBJ carries geometry and basic material data; renderer-specific shading, glass and roughness may need adjustment after import. Native Blender/Cycles or Max/Corona files give the intended material appearance.
