An ICU glass sliding door with a fixed glass panel, moving glazed panel, pull handle, rail, guide and releasing latch. Designed for hospital interiors, architectural scenes and interactive environments. The parts are organized in a functional hierarchy with pivots on their mechanical axes. Moving fittings stay attached throughout the opening and closing cycles.

MODEL

• Polygonal quads and triangles with separate functional parts.
• 9861 polygons and 9687 vertices.
• 19250 triangles in total.
• UV mapped with independent texture atlases.
• Metric scale in meters with the assembly at ground level.

ANIMATION

• Complete opening and closing cycles at 24 fps over 240 sampled frames.
• Animated BLEND, FBX and glTF files.
• Static OBJ file in the closed pose.

TEXTURES

• All PBR maps are 4096 x 4096 PNG files.
• BaseColor, Roughness, Metalness, AO and both OpenGL and DirectX normal maps.
• Separate materials for panels, hardware and glazing where present.
• Physical glass transmission in BLEND and glTF; supported transparency in FBX and OBJ.

FILES

• One archive for each format with its textures.
• Separate original texture archive.
• 15 product images including cover, details, wireframe and UV layouts.
