Bottle Carton Packing Line 3D model

The 3D design of a Bottle Carton Packing Line represents an automated, high-speed packaging system designed for efficient bottle packing into cartons. The structure includes multiple integrated modules, such as a bottle conveyor system, carton erector, bottle loading unit, sealing mechanism, and outfeed conveyor.

The system starts with bottles moving along a conveyor, guided into the carton loading section, where a robotic or mechanical arm accurately places them into pre-formed cartons. The carton sealing unit then secures the package using adhesive tape or glue, followed by quality inspection before final dispatch.

Built with a stainless steel frame, the design ensures durability, hygiene compliance, and seamless integration with existing production lines. The control panel provides real-time monitoring, automation settings, and safety features, making it ideal for beverage, pharmaceutical, and FMCG industries.
