Universal fiber-optic spool mount designed for most FPV frames. The system includes two posts: the front post has a fixed 25° tilt angle, while the rear post is hinged, allowing you to adjust the spacing between posts to match your drone frame while keeping the optimal angle.

Each post is mounted to the drone with two zip ties up to 8 mm wide — strong attachment with no frame modifications required.

The set includes two posts and two spool straps. All parts are ready to use right after printing — no assembly is required.

The spool can be attached in two ways:• using the included straps (designed for TPU printing)• using standard zip ties 6–8 mm wide

A practical and reliable solution for secure and convenient fiber-optic spool mounting on your FPV drone.

3D printing settingsPrinting Recommendations

Printer type: FDM (easy to print on most printers).

Materials:

Main mounting parts — PETG or ABS for better strength.

Straps — TPU for flexibility and secure fastening.

Infill:

Main parts — 25% is sufficient.

Straps — 100% infill for maximum durability.

Additional settings: standard print parameters for the selected material, no post-processing required.
