DESCRIPTION

Model for the RS485 to TTL Board model XY-017.

Its a popular UART Serial Port to RS485 /RS485 to TTL Converter Module SCM Automatic Flow Control. Its used for arduino projects.

Revisions

R1.0

  • A user dectected a deviation of the connection holes by 0.25mm . Corrected
  • Added bottom side.
  • Uploaded an image with PCB dimensions
