Steel Wide Flange Beams HEA Collection Revit STL Printable 3D print model

More than 68 3D Models Collection and 37 Textures [Raw and Painted Steel]! 48 rolled-laser HEA Beams, 8 flats, 12 Bolts&Nuts. Ready for Old and Modern Contemporary Architecture and bolted joints. Real World Scale. STL, REVIT-AUTOCAD, SKETCHUP, VUE!
____________________________________________
More than 68 3D Models Collection and 37 Textures [Raw and Painted Steel]

[Bolts & Nuts Pack Content identical to Product ID: 651759]

European Standard Wide Flange HEA Steel Beams Collection with Flats and Bolts:
UNI 5397 / UNI EN 10034-EN 10088-3: 1D / DIN 1025
UNI EU 58 / UNI EN 10058
ISO 261-ISO 262

Real World Scale Model [SmartCgArt Real World System]. Quads [C4D; OBJ; DXF] & Tris [VUE; 3DS; STL].
STL Print-Ready Printable Steel Beams HEA Series & Bolts and Nuts Valid Mesh Certified.
REVIT-AUTOCAD Architecture DXF blocks ready.
SKETCHUP 3DS Files.

Architecture Use: both Old & Modern Contemporary.
Ready to Build Steel Beams Bolted Joints.

48 Correct Models of HEA Steel Beams, according to the International Standard values and parameters: UNI 5397 / UNI EN 10034-EN 10088-3: 1D / DIN 1025.
8 Steel Flats, according to the International Standard values and parameters: UNI EU 58 / UNI EN 10058.
12 Correct Models of Bolts and Nuts Series M14-M16-M20-M22-M24-M27, according to the International Standard values and parameters: ISO 261 and ISO 262.
37 Textures [Raw and Painted Steel]
10 VUE Alternate Materials

24 Rolled HEA Beams 24 Laser HEA Beams 8 Steel Flats to be used with Bolts and Nuts to build Bolted Joints.

Bolts and Nuts also with washers and 2 Series of Bolts and Nuts: with Thread and without Thread [for low-poly rendering].
For STL users: these ISO 261-ISO 262 threads are for visualization and graphical use only and not for Industrial Production.

In the Package you will find:
1- 24 European Wide Flange Steel HEA Rolled Beams [UNI 5397 / UNI EN 10034];
2- 24 European Wide Flange Steel HEA Laser Beams [UNI 5397 / UNI EN 10034 EN 10088-3: 1D DIN 1025];
3- 8 Steel Flats [80x6; 90x8; 100x10; 110x10; 120x12; 130x12; 140x15; 150x15][UNI EU 58 / UNI EN 10058];
4- 1 Complete Set of 6 Washers, 6 Bolts and 6 Nuts with Thread [M14 to M27: ISO 261-ISO 262];
5- 1 Complete Set of 6 Washers, 6 Bolts and 6 Nuts without Thread [for low-poly rendering];
6- REVIT-AUTOCAD Dxf Beams, Flats and Bolts & Nuts ready to be combined and used;
7- 3DS Version Files ready to be used with SKETCHUP;
8- STL 3D Ready Printable of Beams, Flats and Bolts & Nuts [with Valid Mesh Certificate];
9- 34 High Quality textures for Metal Rendering [1600x1600; 1121x843; 1024x1024; 700x700];
10- 10 Vue Alternate Materials for Steel Chrome, Raw Steel and Painted Steel;
11- Real World Scale SmartCgArt Man Reference System with models [C4D, VUE, 3DS, OBJ, DXF].

POLYGONS/VERTICES COUNT [Values for HEA Beams]
C4D-OBJ-DXF: only/mostly quads [506; 352]
VUE-3DS-STL: triangulated [700; 352]

POLYGONS/VERTICES COUNT [Values for Flats]
C4D-OBJ-DXF: only/mostly quads [1852; 1668]
VUE-3DS-STL: triangulated [3344; 1668]

POLYGONS/VERTICES COUNT [Values for M27 BoltWasherNut with Thread]
C4D-OBJ-DXF: only/mostly quads [9295; 8727]
VUE-3DS-STL: triangulated [17450; 8727]

POLYGONS/VERTICES COUNT [Values for M27 BoltWasherNut without Thread]
C4D-OBJ-DXF: only/mostly quads [2244; 1826]
VUE-3DS-STL: triangulated [3648; 1826]

All the Models are Photoreal and Hi-DEF so they are suitable also for Hi-Def Rendering and Close-Up Shots.

Enjoy THE 4 ARCHITECTS SERIES.

The 4 ARCHITECTS series is developing high-fidelity materials, textures and architectural 3d blocks.

    This product has no reviews yet
    Steel Wide Flange Beams HEA Collection Revit STL Printable
    $165.00
    All prices are exclusive of VAT
    Send your price offer to the author if you want to buy it at lower price.
    Royalty Free License
    Products under Royalty Free License can be used without liability to pay any license fees for<br/> multiple lifelong uses, or sales volume of final product after being paid for once. The product<br/> may not be sold, given, or assigned to another person or entity in the form it is downloaded from the site.<br/> <a href='/pages/terms-and-conditions#general-terms-of-licensing' rel='nofollow' target='_blank'>Read more</a>
