3d Printed Traditional Style Electric Cello 3D print model

This 3d printable electronic Cello features an integrated sound chamber with sound post and bass bar to better replicate the sound of acoustic cellos. It is a full sixed 4:4 cello and uses standard off the shelf cello wood components and strings. It is designed for printing on larger printers such as the Lulzbot Taz or CR10S with a 300mm bed. After 1 year of testing, we are finally ready to release this project. During that 1 year time the cello has remained in tune, playable, and has not shown any strain or cracking. Sound quality seems to be comparable to a mid-range acoustic cello, and can be amplified for concert use quite easily. There is a basic instructions document uploaded, V2 with a more in depth BoM and better diagrams is on the way. This project assumes you have advanced 3d printing skills and basic luthier sills at your disposal. Development thread for this project: https://forum.lulzbot.com/viewtopic.php?f=32&t=5037 In addition to these files you will also need the following: M3 and M5 heat set inserts M3 and M5 bolts of various lengths and M5 nylock nuts 2 conductor + ground Shielded wire (security system wire works well here) 420mm long 8mm steel shafts (3d printer bearing shafts work fine here) Gotoh JCS-1 Stratocaster Jack Plate Fender Stratocaster Style Gotoh BB-02 for 9V Battery Box for Guitar An electric pickup A CV210E preamp, an electrical switch, a ¼” and 1/8” audio jack 7-10 Lbs 3d printer plastic (I used push plastics black ABS, PLA may be a better choice) 4 Bass guitar tuning pegs A cello endpin, saddle, tailpiece, bridge, fingerboard, nut and strings Epoxy This project also includes a full complement of step files for ease of modification. The center chamber section will also be uploaded as a free model to encourage development of alternate center sections. Perhaps a real wood faceplate, or a hybrid plastic and metal resonance block? All proceeds from this project will go to fund additional open source free designs available at https://www.thingiverse.com/piercet/designs Thank you for your interest, and Enjoy!

    This product has no reviews yet
    3d Printed Traditional Style Electric Cello
    $5.00
    All prices are exclusive of VAT
    Save with CGTrader Credits
    Send your price offer to the author if you want to buy it at lower price.
    Royalty Free License
    Products under Royalty Free License can be used without liability to pay any license fees for<br/> multiple lifelong uses, or sales volume of final product after being paid for once. The product<br/> may not be sold, given, or assigned to another person or entity in the form it is downloaded from the site.<br/> <a href='/pages/terms-and-conditions#general-terms-of-licensing' rel='nofollow' target='_blank'>Read more</a>
    Response - % in - h
    3D Print Modeling
    Hire me
    3D model formats
    • Stereolithography (.stl) (42 files)-Version: 2.0cVersion: 1.0cVersion: 1.0cVersion: 1.0dVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0cVersion: 1.0c
    • STEP (.stp) (21 files)-
    • PDF (.pdf)80.6 KB
    3D model details
    • Publish date2018-11-21
    • Model ID#997287
