High-quality 3D assets at affordable prices — trusted by designers, engineers, and creators worldwide. Made with care to be versatile, accessible, and ready for your pipeline.
Included File Formats
This model is provided in 14 widely supported formats, ensuring maximum compatibility:
• - FBX (.fbx) – Standard format for most 3D software and pipelines
• - OBJ + MTL (.obj, .mtl) – Wavefront format, widely used and compatible
• - STL (.stl) – Exported mesh geometry; may be suitable for 3D printing with adjustments
• - STEP (.step, .stp) – CAD format using NURBS surfaces
• - IGES (.iges, .igs) – Common format for CAD/CAM and engineering workflows (NURBS)
• - SAT (.sat) – ACIS solid model format (NURBS)
• - DAE (.dae) – Collada format for 3D applications and animations
• - glTF (.glb) – Modern, lightweight format for web, AR, and real-time engines
• - 3DS (.3ds) – Legacy format with broad software support
• - 3ds Max (.max) – Provided for 3ds Max users
• - Blender (.blend) – Provided for Blender users
• - SketchUp (.skp) – Compatible with all SketchUp versions
• - AutoCAD (.dwg) – Suitable for technical and architectural workflows
• - Rhino (.3dm) – Provided for Rhino users
Model Info
• - All files are checked and tested for integrity and correct content
• - Geometry uses real-world scale; model resolution varies depending on the product (high or low poly)
• • - Scene setup and mesh structure may vary depending on model complexity
• - Rendered using Luxion KeyShot
• - Affordable price with professional detailing
Buy with confidence. Quality and compatibility guaranteed.
If you have any questions about the file formats, feel free to send us a message — we're happy to assist you!
Sincerely,
SURF3D
Trusted source for professional and affordable 3D models.
More Information About 3D Model :
Box Truck Pickup Trailer Wind Deflector Roof Spoiler Cab
A Box Truck Pickup Trailer Wind Deflector Roof Spoiler Cab, more formally known as a Cab Roof Air Deflector or Aerodynamic Fairing for Box Trucks, is an external aerodynamic device mounted atop the roof of the driver's cab on a box truck. While the specific inclusion of Pickup Trailer in the title may suggest application in scenarios involving towing trailers, the fundamental function of the device pertains to managing airflow over the vehicle's frontal profile, particularly the large, blunt face of the cargo box or a towed implement.
Function and Purpose:
The primary purpose of this device is to improve the aerodynamic efficiency of the box truck. The transition area between the cab and the leading edge of the cargo box or a towed trailer is a significant source of aerodynamic drag. As air flows over the relatively low profile of the cab, it encounters the tall, flat surface of the box, creating turbulence, a low-pressure zone immediately behind the cab, and flow separation. This results in substantial air resistance, which increases with vehicle speed.
The cab roof wind deflector is specifically designed to redirect the airflow stream upwards, guiding it smoothly over the top and sides of the cargo box or trailer. By channeling the air, the deflector reduces the pressure differential between the front and rear of the box, minimizes turbulent eddies in the gap between the cab and the box, and encourages the airflow to remain attached to the sides of the cargo body for a longer distance. This reduction in aerodynamic drag directly contributes to several benefits.
Design and Construction:
These deflectors are typically constructed from durable, lightweight materials such as Fiber-Reinforced Polymer (FRP), molded plastics like ABS, or composite materials. They are designed to be rigid and weather-resistant. The shape is generally a curved or angled panel that extends upwards and slightly rearwards from the cab roofline. Some designs may feature adjustable angles to optimize deflection based on the height of the cargo box or trailer. The device is securely mounted to the cab structure, often using bolts or specialized mounting hardware, ensuring stability even at highway speeds. The size and profile of the deflector are engineered to complement the dimensions of standard box truck bodies and trailers.
Benefits:
The installation of a cab roof wind deflector yields several advantages:
- Improved Fuel Efficiency: Reducing aerodynamic drag is the most significant benefit, leading directly to lower fuel consumption, especially at higher speeds where air resistance is the dominant factor in overall vehicle drag.
- Enhanced Vehicle Stability: By reducing turbulence and pressure fluctuations around the front of the cargo box or trailer, the deflector can contribute to improved directional stability, particularly in crosswinds.
- Reduced Wind Noise: Minimizing turbulent airflow in the cab-to-box gap can also lead to a reduction in wind noise experienced within the cab.
- Potential for Reduced Wear: Lower engine load due to reduced drag can potentially lead to less strain on the drivetrain components over time.
Application:
Cab roof wind deflectors are commonly fitted to various types of box trucks, including straight trucks used for local delivery, moving vans, and trucks configured for towing trailers. The effectiveness of the deflector is most pronounced when there is a significant height difference between the cab roof and the top of the cargo box or the towed trailer, as this gap is where the most disruptive turbulence occurs without a deflector.
In summary, the Box Truck Pickup Trailer Wind Deflector Roof Spoiler Cab is an essential aerodynamic accessory for box trucks, specifically the roof-mounted fairing on the cab, serving to optimize airflow, reduce drag, and enhance overall vehicle efficiency, particularly when the vehicle configuration presents a substantial frontal area difference between the cab and the subsequent cargo body or towed unit.
