Hypocycloid Gear 3D model
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
thumbnail
DESCRIPTION

High-precision hypocycloid (cycloidal) gear 3D model designed for smooth, high-efficiency motion transfer in advanced mechanical systems such as cycloidal drives and reduction gearboxes.

This model is generated using accurate geometric parameters, including eccentricity, pin circle radius, and roller diameter, ensuring realistic motion behavior and reliable performance in CAD assemblies, simulations, rendering, and 3D printing.

With 42 segments and teeth, the gear delivers fine motion control and high reduction capability, making it ideal for robotics, automation systems, and precision machinery.

Technical Details

SpecificationsType: Hypocycloid (Cycloidal) GearEccentricity: 1.5 mmNumber of Teeth (Z): 42Segment Count: 42Pin Circle Radius: 66 mmHole Radius: 30 mmRoller Diameter: 3 mmPressure Angle: 55°

3D Model InfoScale: Real-world (millimeters)Units: mmGeometry: Polygonal meshTopology: Clean and optimizedAccuracy: Based on cycloidal gear design principles

Related Tagsdrivemechanismreductionprecisiongearboxeccentricmachineelementcadstlstepengineeringindustrialmechanicalprinting
