- With Texture Maps using Metal-Roughness workflow, available in 1K, 2K, and 4K resolutions, separated by label and weld maps.
- Maps with non-overlapping UVs, allowing easy application of wear effects to the texture.
- A single weld map is used for all weld elements to optimize the model.
Mesh Separated By moving parts with pivots in blender files.
╔ [ Main Dimensions - YOU CAN RESIZE TO FIT YOUR MACHINE ]
│ ├ Internal opening (inside to inside): 260 mm | 26.0 cm | 10.24 in
│ └ Overall external width (outside to outside): 315 mm | 31.5 cm | 12.40 in
╞ Pins
╚ └ Pin diameter: Ø 75 mm | 7.5 cm | 2.95 in
.........................................................................................................................................................
╔ [ File Formats ]
╞ BLENDER .BLEND
╞ .FBX
╞ COLLADA .DAE
╞ .OBJ
╞ glTF 2.0 .glb / .gltf
╚ .STL
.........................................................................................................................................................
╔ [ Mesh ]
╞ 150,545 verts.
╞ 153,990 faces.
╞ 279,121 triangles.
╞ Real-world scale object
╞ .blend file with normals, seams, and weighted normals with 69* smooth.
╞ .blend file with collections and pivot placed
╞ This model is not rigged or animated
╚ Game-optimized topology (not strictly quad-based)
.........................................................................................................................................................
╔ [ Materials and Texturing ]
╞ Model includes materials and texture maps for welds and labels
╞ Metal-Roughness workflow texture set separated by label and weld maps
╚ Texture maps included: 512, 1K, and 2K
.........................................................................................................................................................
╔ [ UV Mapping ]
╞ Materials-only version: single UV unwrap per material, non-overlapping
╞ Textured version: single UV unwrap per material, non-overlapping
╞ Fully unwrapped UVs
╚ 0–1 UV space
.........................................................................................................................................................
╔ [ Disclaimer ]
╞ This model is not designed for CAD use or 3D printing
╞ Created based solely on image references, not official files, assets, or scans
╞ The model may not include all real-world details
╞ The model may not follow exact real-world measurements
╞ Intended for visualization, educational, or gaming purposes only
╞ I do not own any rights to the real-world product, its brand, trademarks, or related patents
╚ This is a fan-made digital product and is not affiliated with or endorsed by the original brand
.........................................................................................................................................................
╔ Thank you!! Hope you like it! I hope you enjoy this model. Feel free to check out my other creations!
╚ For quick support or requests, check the Discord link https://discord.gg/kD7NYxh32e.
