Description
- An Indoor/outdoor 33kV VCB Switchgear Panels with current ratings from 1250A to 2500A. We use 33kV ABB VD4 VCB for our 33kV Switchgear Panels.
- Panel shall be constructed with IP4X degree of protection externally and IP2X between compartments.
- supplied from a single 33kV feeder shall not exceed 45 MVA. If the Network permits a second 33kV feeder, the capacity may be increased to 90MVA.
- A control and relay panel shall include the following: a) Protective and auxiliary relays required for the protection of transformers and lines. b) Indicating instruments with necessary switches c) Control switch for the remote control of 33 KV circuit breaker.
- A relay is basically another word for a switch.
- It could be a switch that turns something on/off or a switch that alternates between two items.
- In turn, a relay panel is a panel that holds one or more relays that sends power or signal to equipment based upon the input received.
- relays for protection of respective circuit along with control equipment, meters etc. as necessary for completeness of the protection/control scheme without overcrowding and cramping. c) The 33KV C&R board panels shall be simplex type for accommodating all the control, protection and metering equipment properly.
- File type: MA,MB,FBX.
- Number of Polygons: 16237.
- Number of Vertices: 18580.
- Number of Tris: 35090.
- Texture format PNG.
- Texture resolution 4K.
