DESCRIPTION

Revit super-window with up to 3 panels, optional transom, surround and sill.Any combination of the following components are possible:

  • Righ and Left Side Panels
  • Middle Panel
  • Transom

Each of these can be a single or double framed window or a fixed panel. Some sample configurations are shown in the Revit Test Project Preview.pdf, notice that this is just one Revit Family and that other combinations are possible.Sill and Surrond can be visible or not per Instance.Finally, there is a 'door' option, when it is checked, a swing (opening) symbol will be visible in floor plan and elevation views.

Super-easy to use and configure... And super powerful ;D
