NYC FIRE ESCAPE LADDER

by Ufuk Orbey (shadedancer619) / Made in: Cinema4D R16 and R14

This is a very nice quality low poly escape ladder model which you easily modify as your wishes.

You can use them in games. Polygon size is low so triangulate them if necessary. Models size is close to real sizes so your characters can easily move between the parts inside the model.

SOURCE FILE (version R14)

The NYC(source).C4D file is a clean source with some parametric primitives, sweep nurbs and cloners. You can easily change the structure by using them. In main structure BRACKET, FLOOR and STEPS are the only objects that you duplicate for make the ladder higher. BASE, SLIDE and TOP objects must be single. The SLIDE should be the part of BASE.

Source model has no textures on it. After you reconstruct the model you should assign textures you want to use in ladder parts. If you want to export it first you must create UV maps by using UV EDIT.

FILE FORMATS

There are six file formats of this model. All of them have their own UV maps and ready to go. IF you make the ladder higher you should just duplicate the FLOOR, STEPS and BRACKET objects. Do not touch their horizontal and depth axis and give 3 meters plus hight to them in Y Axis (or Z in some softwares). This is my dimensions. You can change it.

TEXTURES

They are 2k and 4k maps depend on the objects. This means the textures are high quality stuffs. You may want to use them in games with lower quality versions so the Photoshop says 'resizing is not an issue' :)

COUNTS

• 6 objects
• 2,486 polygons
• 3,358 points
• 5,840 edges
• 30 UW textures
• 1 standart texture
• 6 file formats (C4D, MAX, FBX, DAE, 3DS, OBJ)
• 1 source file (C4D)

Follow my tutorials in youtube: https://www.youtube.com/channel/UCtYvZ8BDNXcx8rfOF-mDxZw

Need some photoshop brushes or images? I'm here: https://shadedancer619.deviantart.com/

Enjoy!

See you...
