DESCRIPTION

I was scouring the internet for circuit board models a while ago. They were quite scarce, indeed. So I am publishing a free model of a printed circuit board I made. It is a semi-fictional power supply. The components are top-notch quality. Materials are provided. Don't like them? Feel free to change them because the model is released under a CC BY-SA liscense. Comment below if you'd like to see more of these. Please understand, while I am an electronics hobbyist, I am not an engineer. If-- for some reason, you decide to build this, I am not responsible for any injuries. Plus, the components I picked were not for use or function, but for show. I hope you like this idea. If you find something that could improve this, don't hesitate to tell me in the comments. Thank you. I used some free assets from other artists in varoius personal projects (y'all are awesome artists), so this is me giving back to this fabulous and talented community.

*This model is 99.9% PBR, and thus is displyed as so. That said; the LED has an 'Add shader' node in its material. Normally this invalidates its PBR status, but I am pretty sure that because it is emissive, it doesn't matter here. If this causes problems, I will fix it.

Related Tagscircuitcomputer equipmentmotherboardtechnologyfree
free for commercial
open source
electronicscomputerelectricalpowerhigh polyhi polypolydetailedother
