AKK or Fatshark VRX Enclosure for Walksnail Avatar X 3D print model

3D Model: AKK Diversity VRX Enclosure for Walksnail Avatar X Goggles (Fatshark Compatible)

This custom enclosure is designed to integrate the AKK Diversity receiver module with Walksnail Avatar X Goggles, providing added flexibility for users who prefer not to disassemble their goggles to install modifications. It’s also fully compatible with Fatshark modules.

Key Features:

Cooling Enhancement: Includes a 30x30mm fan positioned for efficient cooling of the VRX module, reducing thermal noise in the receiver, and targeting the right side of the goggles, where heat typically accumulates. Quick Attach & Detach System: The enclosure mounts using a dovetail adapter, which secures to the goggles via standard RP-SMA-F antenna connectors. This design allows for fast removal without unscrewing the antennas. (You can additionally secure the dovetail to the housing with an M2 screw) Adapter Compatibility: The dovetail adapter supports mounting to SMA adapters with rubber gaskets, for users with custom or replaced antennas.

Module Components:

AKK Diversity RX URUAV 5.8G RX PORT Receiver Board with DCDC converter, power, and composite video connectors (commonly available on sites like AliExpress) 5V 30x30mm Fan (compatible with Raspberry Pi 4B/3B+), max thickness: 10mm

The case is secured with M2 Brass Hot Insert Nuts - 3.2mm OD, 4mm Length (4pcs) and Flat M2 Screws, 4mm Length (4pcs)The adapter board is attached with Flat M2 Screws (2pcs), 6mm Length and the same Hot Insert Nuts (2pcs) through plastic washers (2pcs)

Manufacturing Information:

Prototype: Printed using FDM technology Latest Model: Produced using MJF technology, which is the preferred option for optimal durability and finish quality.

Assembly instructions are provided via a link to Google Drive with photo guides.https://drive.google.com/drive/folders/1Dq6H4zLCMa-UgtxgOnbitbShyDn6pUuc?usp=sharing
