Semi dump truck toy - fully 3D printable - assembly experience 3D print model

Fully printable - no support - no glue - single color 3D printer

This is a semi truck toy with a dump truck trailer.

Assembly video (semi truck) https://youtu.be/TJCMTOk385A Assembly video (tank trailer) https://youtu.be/-EAHEBORbbY

The semi truck is more or less the same as the one with the tank trailer: https://www.cgtrader.com/3d-print-models/games-toys/toys/semi-truck-toy-fully-3d-printable-assembly-experience

For the dump trailer print as many middle modules as you want to get the tank length that you want. You will need however to print the longer dump_semi_connector_L.stl and more connectors and screws for this!

You can also make a short version with the pieces from this model (see 3rd to 5th pics).

The tolerance for pieces that need to fit tightly is 0.1mm, for pieces that need to allow movement (like screws and axles) 0.3mm or more.

Printing list: Nb. STL file name rezolution support colour (my make)

• 1x articulation_plate.stl 0.16mm no orange
• 1x articulation_screw_semi_truck.stl 0.16mm no gray
• 3x axle_back.stl 0.16mm no gray
• 1x axle_front.stl 0.16mm no gray
• 1x backhead_semitruck.stl 0.12mm no black-white

• 1x backhead_trailer.stl 0.12mm no black-white
• 0x back_light.stl 0.16mm no
• 4x back_light_with_flat_cut.stl 0.16mm no orange

• 2x back_light_with_flat_cut.stl 0.16mm no red

• 2x back_light_with_flat_cut.stl 0.16mm no white
• 1x base_semitruck_short_left.stl 0.16mm no green
• 1x base_semitruck_short_right.stl 0.16mm no green

• 1x base_trailer_left.stl 0.16mm no green

• 1x base_trailer_right.stl 0.16mm no green

• 1x cabin_cap.stl 0.16mm no orange

• 1x cabin_light_holes_spare_wheel.stl 0.16mm no green
• 8x cap_double_rim_v2.stl 0.16mm no gray
• 2x cap_double_rim_v2.stl 0.16mm no orange

• 2x cap_single_rim.stl 0.16mm no gray
• 4x connector_base_tank.stl 0.16mm no green
• 1x dump_back_articulation.stl 0.16mm no black
• 1x dump_module_art_trailer.stl 0.16mm no orange
• 1x dump_module_door.stl 0.16mm no orange
• 1x dump_module_end.stl 0.16mm no yellow
• 3x dump_module_inner.stl 0.16mm no yellow
• 1x dump_module_start.stl 0.16mm no yellow
• 1x dump_semi_connector.stl 0.16mm no black
• 0x dump_semi_connector_L.stl 0.16mm no

• 1x exhaust.stl 0.16mm no black
• 1x front_grill.stl 0.12mm no black-white-black
• 1x front_lights.stl 0.12mm no orange-white
• 2x front_light_round.stl 0.16mm no white

• 1x interieur.stl 0.16mm no gray

• 1x interieur_base.stl 0.16mm no red

• 1x mirrors 0.12mm no black(TPU)

• 4x rim_double.stl 0.16mm no white
• 2x rim_double.stl 0.16mm no green
• 2x rim_single.stl 0.16mm no green
• 2x rim_single.stl 0.16mm no orange
• 2x roof_light.stl 0.16mm no orange
• 1x screw_gear_knob.stl 0.16mm no black

• 37x screw_l6mm.stl 0.16mm no blue

• 15x screw_l9mm.stl 0.16mm no black
• 10x screw_l13mm.stl 0.16mm no orange

• 1x screw_for_spare_wheel_on_cabin.stl 0.16mm no orange
• 0x sleeping_screw_l9mm.stl 0.16mm no

• 0x sleeping_screw_l13mm.stl 0.16mm no

• 1x spare_wheel_holder.stl 0.16mm no orange
• 1x steering_wheel.stl 0.16mm no black
• 14x tank_screw_pad.stl 0.16mm no orange

• 10x tire_outter_cut.stl 0.16mm no black(TPU)

• 6x tire_simple.stl 0.16mm no black(TPU)

• 1x tool_box_left.stl 0.16mm no orange

• 1x tool_box_right.stl 0.16mm no orange
• 1x wheel_house_back_left.stl 0.16mm no gray

• 1x wheel_house_back_right.stl 0.16mm no gray

• 1x wheel_house_front_left.stl 0.16mm no black

• 1x wheel_house_front_right.stl 0.16mm no black

• 1x wheel_house_simple_left.stl 0.16mm no black

• 1x wheel_house_simple_right.stl 0.16mm no black


Observations:

• all objects already have the intended print direction in the STL files!
• most of the parts were printed with PLA. only the tires and the mirrors were printed from TPU (flexible material)
• screws... there are also sleeping screws STLs included these are printed on the side which makes them a lot stronger the drawback is that these don't close the holes completely... So use as many sleeping screws as you can if the toy is going to be played with, and only normal/round ones otherwise
