Dungeon Magnetic System
Creating a modular 3D-printed dungeon system with magnetic spheres offers a versatile and engaging way to design customizable dungeon environments for tabletop games like Dungeons & Dragons. Here's a detailed description of the system:
1.1. TilesBase Tiles: Square tiles (e.g., 1x1 inch, 2x2 inch) that form the floor of the dungeon.Wall Tiles: Sections that clip onto the edges of the base tiles to create walls..1.2. ConnectorsCorner Connectors: L-shaped pieces to join walls at right angles.Straight Connectors: Pieces to connect walls in a straight line.T-Junction Connectors: T-shaped pieces for connecting three walls.X-Junction Connectors: Cross-shaped connectors for four-way intersections.1.3. Special FeaturesDoors: Removable door pieces that fit into wall sections.Stairs and Elevation: Stair pieces to create multi-level dungeons.Trap Tiles: Specialized tiles with removable sections to simulate traps.
2.1. Magnetic SpheresEmbedding: Small neodymium spheres (3/16 inch - 5mm in diameter) embedded at strategic points on the tiles and connectors. Each corner of a tile has a recess for a magnetic sphere.Alignment: Magnetic poles are correctly aligned to allow seamless attachment and detachment by rotating themselves.2.2. Magnetic InsertsInserts in Walls and Connectors: Small spherical magnets embedded in the walls and connectors to facilitate easy and secure attachment.Recessed Slots: Designed recessed slots in the tiles and connectors where the magnets can be pushed in post-printing.
3.1. CompatibilityUniversal Fit: Ensure all pieces have a standardized connection system so they can be easily mixed and matched.3.2. Printing and AssemblyPrint Orientation: Design pieces to be printed with minimal supports to save material and reduce post-processing.Assembly Instructions: Provide clear instructions for assembling the pieces, including where to place magnets and how to connect different components.
Example Use Case
A game master sets up a dungeon using the 3D-printed modular system. They start with a 4x4 grid of base tiles, snapping walls into place using the magnetic connectors. They add a trap tile with a hidden spike pit and connect a stairway to a higher level. Doors are inserted into selected wall sections, and the dungeon is populated with furniture and props. Players can easily navigate through the dungeon, and the game master can quickly reconfigure the layout for different scenarios.
By combining the flexibility of modular design with the ease of magnetic connections, this system provides a dynamic and customizable dungeon-building experience for tabletop gaming enthusiasts.
